Portable Data Terminal
A60
dual band WiFi and 4G all Netcom, with faster operation speed,
smooth operation, higher speed and stable data transmission.
widely used in warehouse management, express logistics, factories, parking fees,
supermarket management
Main Features
- 5.99 inches IPS color display,resolution 1080*2160
- 1D/2D barcode with quick identification
- Android 10 customized system with high performance Qualcomm Octa-Core CPU
Try On The Touch
Spesifications
| CPU | Cortex-A76/A53 Octa-core 64-bit 2.0GHz high-performance processor |
| RAM | 4GB |
| ROM | 64GB |
| ROM | 64GB |
| System | Android 10.0 |
| WLAN | Dual frequency 2.4GHz/5GHz, support IEEE 802 a/b/g/n/ac protocol |
| WWAN | 2G: GSM (Mobile/Unicom), CDMA (Telecom) 3G: WCDMA (Unicom), CDMA2000 (Telecom), TD-SCDMA (Mobile) 4G: TD-LTE (mobile), FDD-LTE (unicom, telecommunications) 5G: Mobile 5G, China Unicom 5G, Telecom 5G |
| Bluetooth | Support BT 5.0 Transmission distance 5-10 meters |
| GNSS | Support Gps, Galileo, Glonass, Beidou |
| Dimensions | 164.5mm×79.4mm×12.3mm |
| Weight | <265g (Depends on device function configuration) |
| Display | 5.99 inches IPS color display,resolution 1080*2160 |
| TP | Supports multi-touch Supported gloves and wet hands |
| Battery capacity | (3.8V4200MAh) |
| Expansion Card slot | Nano SIM card |
| Communication interface | Type-C USB x 1, OTG |
| Audio | Speaker (mono), Microphone x 2 , Earpiece, Vibration motor |
| Keypad | Power button, Volume +/- button,Scan button × 2 Handle scan button ×1 |
| Sensors | Gravity sensor, Light sensor, Proximity sensor, Gyroscope, electronic compass |
| 2D Imager scanner | Honeywell N6703 |
| 2D Symbologies | PDF417,Micro PDF417,GS1 Composite,Aztec Code,Data Matrix,QR Code,Micro QR Code, Maxicode,Hanxin Code,etc. |
| Rear camera | 16MP HD camera,Support auto focus, 2MP auxiliary camera Flash, Anti-shake, Macro shooting |
| Front camera | 5MP color camera |
| Features | Support fingerprint unlocking and taking pictures |
| Frequency | 13.56MHz |
| Protocol | Support ISO14443A/B, 15693 agreement |
| Distance | 2cm-5cm |
| Input | English, Pinyin, Five strokes, Handwriting input, Support soft keypad |
| Language | Chinese, English, Korean, Japanese, Malaysian,etc. |
| Operating temperature | -20°C - 55°C |
| Storage temperature | -40°C - 70°C |
| Environment humidity | 5%RH--95%RH(no condensation) |
| Drop specification | temperature range, 6 sides can withstand a height of 1.2 meters 30 impacts of falling to the marble floor |
| Sealing | IP66 |
| Standard | Adapter, Data cable, Protective film, Instruction manual |
