Thermal Receipt Printer

BTP 3250

Kassen BTP3250 is a receipt printer equipped with thermal printing technology which can create clear and easy to read receipts. Equipped with an auto cutter feature, so receipts will be cut automatically after printing, saving time and increasing operational efficiency.

Main Features

  • Direct thermal printing method (ink ink / cartridge ribbon)
  • Supports Bluetooth & USB connections
  • Auto cutter
  • Can be connected to cash drawer
  • Drop-in paper refill method
  • Supports Android, iOS, Windows
  • Print speed 200mm/s
  • Official guarantee
Brochure
Driver For Windows
Manual Book
Certificate
Try On The Touch

Spesifications

ModelBTP3250
Printing MethodDirect Thermal
Paper Width80mm
Print Width72mm
Paper Roll Diameter82mm
Resolution203 DPI
Printing Speed200mm/s
InterfaceUSB + Bluetooth
Line Spacing203 DPI
Column Number48-font A / 64-font B
Character SizeANK Font; Font A; 12 X 24 dots; Font B 9 X 17 dots; Chinese character; 24 X 24 dots
Auto CutterSemi cut
Cutter life1.500.000 times
Extension Character SheetGB-18030
Barcode TypesUPC-A / UPC-E / JAN13 (EAN13) / JAN8 (EAN8) / ITF / CODABAR / CODE 39 /CODE 93 / CODE 128 / QR CODE
Input Buffer8KB
NV Flash256KB
Power AdaptorDC 24V / 1.25A
Printer InputDC 24V / 1.25A
CashdrawerRJ11 port
Weight0.84kg
Dimensions130.2mm*167mm*131.5mm
Work EnvironmentTemparature : 5°C - 40°C, Humidity : 20% - 90%
Storage EnvironmentTemperature : -25°C - 55°C, Humidity : 20% - 93%
Print Head Life150KM
EmulationESC/POS
DriverWindows driver
UtilityWindows tool, Android setting tool
SDKAndroid, C#, IOS, Linux
